N-(3,5-Di­chloro-4-meth­oxy­phen­yl)acetamide

Uppu, R.M.; Bai, S.V.; Mensah, P.F.; Li, G.; Fronczek, F.R.

doi:10.1107/S241431462600502X

organic compounds

IUCrDATA

ISSN: 2414-3146

Volume 11| Part 5| May 2026| x260502

https://doi.org/10.1107/S241431462600502X

Open

access

N-(3,5-Dichloro-4-methoxyphenyl)acetamide

Rao M. Uppu,^a ^* Sindhu V. Bai,^a Patrick F. Mensah,^b Guoqiang Li ^c and Frank R. Fronczek ^d

^aDepartment of Environmental Toxicology, Southern University and A&M College, Baton Rouge, Louisiana 70813, USA, ^bDepartment of Mechanical Engineering, Southern University and A&M College, Baton Rouge, Louisiana 70813, USA, ^cDepartment of Mechanical and Industrial Engineering, Louisiana State University, Baton Rouge, Louisiana 70803, USA, and ^dDepartment of Chemistry, Louisiana State University, Baton Rouge, Louisiana 70803, USA
^*Correspondence e-mail: [email protected]

Edited by W. T. A. Harrison, University of Aberdeen, United Kingdom (Received 8 May 2026; accepted 12 May 2026; online 22 May 2026)

The title compound, C₉H₉Cl₂NO₂, crystallizes in the triclinic space group P1 with six molecules in the asymmetric unit. Structure determination at 100 K from a two-component twin crystal shows that the six crystallographically independent molecules adopt closely similar conformations. The dichlorophenyl and acetamide planes form a dihedral angle of ca. 10.0° (mean of six molecules), while the methoxy substituent is oriented nearly orthogonal to the aromatic ring (mean dihedral angle = 88.5°). In the extended structure, the molecules are linked by N—H⋯O hydrogen bonds into infinite chains extending along [110], giving rise to three independent motifs of alternating molecules (ABABAB⋯, CDCDCD⋯, and EFEFEF⋯). Numerous weak C—H⋯O and C—H⋯Cl hydrogen bonds consolidate the packing.

Keywords: crystal structure; cellular oxidants; chlorinated methacetin; hypochlorous acid-hypochlorite; mitotoxicity; protonophores.

CCDC reference: 2536293

Structure description

A chlorinated derivative of methacetin, N-(3,5-dichloro-4-methoxyphenyl)acetamide, can be formed during hypochlorous acid (HOCl)/hypochlorite (ClO⁻)-mediated oxidation; such electrophilic chlorination reactions are of potential relevance to xenobiotic biotransformation and mineralization (Acero et al., 2010 ; Hines et al., 2026 ). Methacetin belongs to the class of alkoxyacetanilides that includes phenacetin (C₁₀H₁₃NO₂), an early synthetic analgesic and antipyretic introduced in the late 19th Century following the clinical use of acetanilide (Antifebrin; C₈H₉NO), whose use declined due to toxicity concerns (Merck, 1899 ). Methacetin itself was not used as an analgesic–antipyretic but has been employed since the 1990s in liver function testing via the [¹³C-methyl]-methacetin breath test, which monitors CYP-mediated oxidative O-dealkylation (primarily by CYP1A2) through measurement of ¹³CO₂ in exhaled breath (Buechter & Gerken, 2022 ; Gairing et al., 2022 ; Santol et al., 2024 ).

In this context, and in view of the susceptibility of methacetin and related compounds to biotransformation by cellular oxidants such as HOCl/ClO⁻ (Hines et al., 2026) and peroxynitrite (ONOOH)/peroxynitrite (ONOO⁻) (Hines et al., 2025 ), as well as the potential formation of protonophoric metabolites, including N-(3,5-dichloro-4-methoxyphenyl)acetamide via oxidative O-dealkylation (Uppu & Fronczek, 2026a ,b ), we have synthesized and structurally characterized the title compound, C₉H₉Cl₂NO₂, (I) (Fig. 1) (Bai et al., 2026 ).

Figure 1
The molecular structure of one of the six molecules of (I), with atom labeling and displacement ellipsoids drawn at the 50% probability level.

The asymmetric unit of (I) contains six independent molecules (Z′ = 6), an unusually high value for a compound of this size, indicative of packing-stabilized conformational multiplicity. Only about 0.057% of structures in the Cambridge Structural Database (Groom et al., 2016 ) have Z′ = 6. Each molecule comprises a dichlorinated aromatic ring bearing methoxy and acetamide substituents. The mean dihedral angle between the aromatic ring and the acetamide plane is approximately 10°, indicating near coplanarity, whereas the methoxy group is oriented nearly orthogonal to the ring (ca. 88°). Bond distances and angles are within expected ranges, with C—Cl distances averaging ca. 1.73 Å.

In the extended structure (Figs. 2–5 ), N—H⋯O hydrogen bonds link the molecules into chains extending along the [1 $[\overline{1}]$ 0] direction. Three distinct but structurally analogous chain motifs (ABABAB⋯, CDCDCD⋯ and EFEFEF⋯) arise from the six independent molecules. These interactions, together with longer C—H⋯O and C—H⋯Cl contacts (Table 1) further consolidate the crystal packing. The presence of multiple independent molecules and twinning reflects subtle packing-driven stabilization of quasi-equivalent conformers rather than large intrinsic conformational differences.

Table 1
Hydrogen-bond geometry (Å, °)

D—H⋯A	D—H	H⋯A	D⋯A	D—H⋯A
N1—H1N⋯O5	0.90 (2)	2.08 (2)	2.932 (4)	158 (4)
C2—H2⋯O1	0.95	2.29	2.885 (5)	120
C6—H6⋯O5	0.95	2.63	3.406 (6)	140
C8—H8B⋯Cl8	0.98	2.92	3.842 (5)	157
C9—H9B⋯O4	0.98	2.52	3.437 (6)	157
N5—H5N⋯O11ⁱ	0.90 (2)	2.03 (2)	2.922 (4)	174 (5)
C38—H38⋯O9	0.95	2.29	2.878 (6)	120
C44—H44C⋯Cl10ⁱⁱ	0.98	2.90	3.780 (5)	150
C45—H45B⋯O12	0.98	2.46	3.312 (5)	146
N6—H6N⋯O9ⁱⁱⁱ	0.90 (2)	2.04 (2)	2.933 (4)	172 (5)
C47—H47⋯O11	0.95	2.32	2.899 (6)	118
C51—H51⋯O9ⁱⁱⁱ	0.95	2.63	3.409 (5)	139
C53—H53B⋯Cl12ⁱⁱⁱ	0.98	2.89	3.829 (5)	161
C53—H53C⋯O11^iv	0.98	2.71	3.291 (5)	119
C54—H54B⋯O10^v	0.98	2.59	3.443 (6)	145
N4—H4N⋯O3^vi	0.90 (2)	2.03 (2)	2.924 (4)	170 (5)
C29—H29⋯O7	0.95	2.34	2.915 (6)	118
C33—H33⋯O3^vi	0.95	2.61	3.389 (5)	140
C35—H35B⋯O1^vii	0.98	2.57	3.311 (5)	133
C36—H36C⋯O6^vi	0.98	2.51	3.438 (6)	157
N3—H3N⋯O1^viii	0.89 (2)	2.08 (2)	2.910 (4)	155 (4)
C20—H20⋯O5	0.95	2.26	2.862 (6)	120
C26—H26A⋯O1^viii	0.98	2.51	3.393 (5)	150
C26—H26B⋯Cl4	0.98	2.87	3.771 (5)	154
C26—H26C⋯O7	0.98	2.57	3.291 (6)	131
C27—H27A⋯Cl10	0.98	2.97	3.604 (5)	123
C27—H27C⋯O8	0.98	2.39	3.304 (6)	154
N2—H2N⋯O7^ix	0.89 (2)	2.02 (2)	2.900 (4)	169 (4)
C11—H11⋯O3	0.95	2.24	2.860 (6)	122
C17—H17A⋯O7^ix	0.98	2.56	3.391 (5)	143
C17—H17C⋯Cl6	0.98	2.83	3.772 (5)	162
C18—H18B⋯O2^v	0.98	2.47	3.319 (6)	144
Symmetry codes: (i) ; (ii) ; (iii) ; (iv) ; (v) ; (vi) ; (vii) ; (viii) ; (ix) .

Figure 2
View of the six crystallographically independent molecules in the asymmetric unit of (I), illustrating the conformational similarity among the independent molecules.

Figure 3
Partial packing diagram of (I) showing the N—H⋯O hydrogen-bonded chains propagating along the [1 $[\overline{1}]$ 0] direction.

Figure 4
Detail of one hydrogen-bonded chain in (I), highlighting the alternating molecular arrangement within the chain motif.

Figure 5
View of the crystal packing of (I) approximately along the b axis, showing the arrangement of molecules within the unit cell.

Synthesis and crystallization

The title compound was synthesized by acetylation of 3,5-dichloro-4-methoxyaniline with acetic anhydride in acetic acid as solvent. The anhydride, typically taken in 20% molar excess (6.4 mmol), was reacted with 5.3 mmol of the aniline derivative in 10 ml of acetic acid, and the mixture was stirred using a magnetic stir bar for 1 h at room temperature. The solvent was then evaporated, and the product was purified by recrystallization from ethanol solution. Crystals of (I) suitable for X-ray diffraction were obtained by slow cooling and evaporation of a hot ethanolic solution under ambient conditions.

Refinement

Crystallographic and refinement data are summarized in Table 2. All H atoms were located in difference maps and those on C were thereafter treated as riding in geometrically idealized positions with C—H distances 0.95 Å for phenyl and 0.98 Å for methyl. The coordinates of the N-bound hydrogen atoms were refined with N—H distances restrained to be equal. U_iso(H) values were assigned as 1.2U_eq for the attached atom (1.5 for methyl). The crystal chosen for data collection was found to be a two-component pseudomerohedral twin by twofold rotation around (001) (real space) or [0 $[\overline{1}]$ 2] (reciprocal space). The twin law is (–1 0 0 / 0 −1 0 / 0 −1 1), and the twin domains refined to 0.7468 (4)/0.2532 (4).

Table 2
Experimental details

Crystal data
Chemical formula	C₉H₉Cl₂NO₂
M_r	234.07
Crystal system, space group	Triclinic, P $[\overline{1}]$
Temperature (K)	100
a, b, c (Å)	8.1860 (8), 8.7093 (8), 44.343 (4)
α, β, γ (°)	84.465 (4), 88.209 (4), 71.399 (3)
V (Å³)	2982.3 (5)
Z	12
Radiation type	Cu Kα
μ (mm⁻¹)	5.66
Crystal size (mm)	0.12 × 0.11 × 0.02

Data collection
Diffractometer	Bruker D8 Venture DUO with Photon III C14
Absorption correction	Multi-scan (SADABS; Krause et al., 2015 )
T_min, T_max	0.679, 0.895
No. of measured, independent and observed [I > 2σ(I)] reflections	100590, 12442, 6847
R_int	0.067
(sin θ/λ)_max (Å⁻¹)	0.637

Refinement
R[F² > 2σ(F²)], wR(F²), S	0.033, 0.099, 1.03
No. of reflections	12442
No. of parameters	789
No. of restraints	15
H-atom treatment	H atoms treated by a mixture of independent and constrained refinement
Δρ_max, Δρ_min (e Å⁻³)	0.44, −0.50
Computer programs: APEX5 and SAINT (Bruker, 2016 ), SHELXT2018/2 (Sheldrick, 2015a ), SHELXL2019/1 (Sheldrick, 2015b ), Mercury (Macrae et al., 2020 ) and publCIF (Westrip, 2010 ).

Structural data

CCDC reference: 2536293

Crystal structure: contains datablock I. DOI: https://doi.org/10.1107/S241431462600502X/hb4561sup1.cif

Structure factors: contains datablock I. DOI: https://doi.org/10.1107/S241431462600502X/hb4561Isup2.hkl

Supporting information file. DOI: https://doi.org/10.1107/S241431462600502X/hb4561Isup3.cml

checkCIF report

Computing details top

N-(3,5-Dichloro-4-methoxyphenyl)acetamide top

Crystal data top

C₉H₉Cl₂NO₂	Z = 12
M_r = 234.07	F(000) = 1440
Triclinic, P1	D_x = 1.564 Mg m⁻³
a = 8.1860 (8) Å	Cu Kα radiation, λ = 1.54184 Å
b = 8.7093 (8) Å	Cell parameters from 9974 reflections
c = 44.343 (4) Å	θ = 5.4–78.4°
α = 84.465 (4)°	µ = 5.66 mm⁻¹
β = 88.209 (4)°	T = 100 K
γ = 71.399 (3)°	Lath fragment, colourless
V = 2982.3 (5) Å³	0.12 × 0.11 × 0.02 mm

Data collection top

Bruker D8 Venture DUO with Photon III C14 diffractometer	6847 reflections with I > 2σ(I)
Radiation source: IµS 3.0 microfocus	R_int = 0.067
φ and ω scans	θ_max = 79.1°, θ_min = 2.0°
Absorption correction: multi-scan (SADABS; Krause et al., 2015)	h = −10→10
T_min = 0.679, T_max = 0.895	k = −11→10
100590 measured reflections	l = −55→55
12442 independent reflections

Refinement top

Refinement on F²	Hydrogen site location: mixed
Least-squares matrix: full	H atoms treated by a mixture of independent and constrained refinement
R[F² > 2σ(F²)] = 0.033	w = 1/[σ²(F_o²) + (0.0445P)² + 0.6459P] where P = (F_o² + 2F_c²)/3
wR(F²) = 0.099	(Δ/σ)_max = 0.001
S = 1.03	Δρ_max = 0.44 e Å⁻³
12442 reflections	Δρ_min = −0.50 e Å⁻³
789 parameters	Extinction correction: SHELXL2019/1 (Sheldrick 2015b), Fc^*=kFc[1+0.001xFc²λ³/sin(2θ)]^-1/4
15 restraints	Extinction coefficient: 0.00015 (3)
Primary atom site location: dual

Special details top

Geometry. All esds (except the esd in the dihedral angle between two l.s. planes) are estimated using the full covariance matrix. The cell esds are taken into account individually in the estimation of esds in distances, angles and torsion angles; correlations between esds in cell parameters are only used when they are defined by crystal symmetry. An approximate (isotropic) treatment of cell esds is used for estimating esds involving l.s. planes.

Refinement. Refined as a 2-component twin.

Fractional atomic coordinates and isotropic or equivalent isotropic displacement parameters (Å²) top

	x	y	z	U_iso*/U_eq
Cl1	−0.00483 (15)	0.97432 (12)	0.05545 (3)	0.0268 (2)
Cl2	0.47196 (16)	0.37931 (11)	0.05965 (3)	0.0255 (2)
O1	0.1580 (4)	0.9282 (3)	0.16586 (7)	0.0213 (6)
O2	0.1882 (4)	0.6586 (4)	0.03202 (8)	0.0246 (7)
N1	0.3698 (5)	0.7079 (4)	0.14998 (9)	0.0187 (7)
H1N	0.475 (3)	0.635 (4)	0.1534 (11)	0.022*
C1	0.3177 (6)	0.7077 (5)	0.11994 (10)	0.0184 (8)
C2	0.1895 (6)	0.8328 (5)	0.10488 (10)	0.0189 (8)
H2	0.128577	0.927058	0.114605	0.023*
C3	0.1510 (5)	0.8175 (4)	0.07479 (11)	0.0182 (8)
C4	0.2366 (6)	0.6783 (5)	0.05979 (11)	0.0208 (9)
C5	0.3642 (6)	0.5572 (5)	0.07631 (10)	0.0177 (8)
C6	0.4053 (6)	0.5690 (5)	0.10559 (11)	0.0200 (9)
H6	0.493070	0.483002	0.116039	0.024*
C7	0.2925 (6)	0.8119 (5)	0.17087 (10)	0.0180 (8)
C8	0.3809 (6)	0.7742 (5)	0.20090 (11)	0.0223 (9)
H8A	0.480478	0.675313	0.200479	0.033*
H8B	0.300413	0.757218	0.216703	0.033*
H8C	0.419818	0.865149	0.205219	0.033*
C9	0.2775 (7)	0.7144 (6)	0.00677 (11)	0.0311 (11)
H9A	0.246659	0.679406	−0.011999	0.047*
H9B	0.402217	0.668190	0.009983	0.047*
H9C	0.244093	0.833418	0.005218	0.047*
Cl9	0.14784 (13)	0.98252 (11)	0.37794 (3)	0.0224 (2)
Cl10	0.63149 (13)	0.39432 (10)	0.39756 (3)	0.0201 (2)
O9	0.6742 (4)	0.5843 (3)	0.49870 (8)	0.0208 (7)
O10	0.3609 (4)	0.6548 (3)	0.36213 (7)	0.0179 (6)
N5	0.4396 (4)	0.7919 (3)	0.48021 (9)	0.0159 (7)
H5N	0.361 (5)	0.882 (4)	0.4858 (12)	0.019*
C37	0.4303 (5)	0.7519 (4)	0.45073 (10)	0.0122 (7)
C38	0.5306 (5)	0.6050 (4)	0.43947 (10)	0.0150 (8)
H38	0.612871	0.524658	0.452060	0.018*
C39	0.5071 (5)	0.5792 (4)	0.40962 (10)	0.0148 (8)
C40	0.3910 (5)	0.6900 (4)	0.39042 (11)	0.0155 (8)
C41	0.2938 (5)	0.8361 (4)	0.40140 (11)	0.0165 (8)
C42	0.3123 (5)	0.8687 (4)	0.43071 (10)	0.0147 (8)
H42	0.245419	0.970038	0.437520	0.018*
C43	0.5556 (5)	0.7111 (4)	0.50249 (11)	0.0170 (8)
C44	0.5286 (5)	0.7891 (4)	0.53143 (11)	0.0173 (8)
H44A	0.479197	0.907305	0.527169	0.026*
H44B	0.639311	0.763272	0.541827	0.026*
H44C	0.449483	0.748193	0.544375	0.026*
C45	0.4658 (6)	0.7017 (5)	0.33853 (11)	0.0216 (9)
H45A	0.435942	0.673462	0.319028	0.032*
H45B	0.587735	0.644149	0.342938	0.032*
H45C	0.444777	0.819290	0.337605	0.032*
Cl11	0.66132 (13)	0.97484 (11)	0.38871 (3)	0.0228 (2)
Cl12	1.13883 (14)	0.37932 (10)	0.39285 (3)	0.0219 (2)
O11	0.8284 (4)	0.9267 (3)	0.49911 (8)	0.0187 (6)
O12	0.8529 (4)	0.6592 (3)	0.36509 (8)	0.0196 (6)
N6	1.0365 (4)	0.7074 (3)	0.48312 (9)	0.0162 (7)
H6N	1.124 (5)	0.621 (4)	0.4906 (12)	0.019*
C46	0.9859 (5)	0.7058 (4)	0.45352 (10)	0.0148 (8)
C47	0.8566 (5)	0.8326 (4)	0.43774 (11)	0.0168 (8)
H47	0.796216	0.927886	0.447207	0.020*
C48	0.8185 (5)	0.8165 (4)	0.40814 (11)	0.0174 (8)
C49	0.9033 (5)	0.6776 (4)	0.39348 (10)	0.0152 (8)
C50	1.0322 (5)	0.5558 (4)	0.40942 (11)	0.0167 (8)
C51	1.0733 (5)	0.5683 (4)	0.43877 (11)	0.0156 (8)
H51	1.161907	0.482496	0.449082	0.019*
C52	0.9593 (5)	0.8102 (4)	0.50426 (10)	0.0159 (8)
C53	1.0489 (5)	0.7750 (4)	0.53471 (11)	0.0202 (9)
H53A	1.164119	0.696101	0.532945	0.030*
H53B	0.981555	0.730051	0.549656	0.030*
H53C	1.058889	0.875932	0.541243	0.030*
C54	0.9436 (6)	0.7131 (5)	0.34042 (12)	0.0274 (10)
H54A	0.900187	0.694115	0.321245	0.041*
H54B	1.066935	0.652631	0.342248	0.041*
H54C	0.926054	0.829582	0.340847	0.041*
Cl7	0.67080 (14)	0.02552 (11)	0.27795 (3)	0.0242 (2)
Cl8	0.19360 (15)	0.62021 (11)	0.27378 (3)	0.0230 (2)
O7	0.5051 (4)	0.0727 (3)	0.16761 (7)	0.0201 (6)
O8	0.4796 (4)	0.3422 (3)	0.30151 (8)	0.0192 (6)
N4	0.2948 (5)	0.2923 (4)	0.18317 (9)	0.0169 (7)
H4N	0.211 (5)	0.382 (4)	0.1755 (12)	0.020*
C28	0.3486 (5)	0.2934 (4)	0.21338 (10)	0.0159 (8)
C29	0.4759 (5)	0.1688 (4)	0.22922 (11)	0.0186 (9)
H29	0.537412	0.073352	0.219889	0.022*
C30	0.5112 (5)	0.1857 (4)	0.25838 (11)	0.0182 (8)
C31	0.4322 (6)	0.3209 (4)	0.27336 (11)	0.0178 (9)
C32	0.3037 (6)	0.4447 (4)	0.25708 (11)	0.0184 (9)
C33	0.2582 (5)	0.4317 (4)	0.22761 (10)	0.0173 (8)
H33	0.167199	0.515508	0.217413	0.021*
C34	0.3722 (5)	0.1887 (4)	0.16262 (10)	0.0165 (8)
C35	0.2848 (6)	0.2272 (4)	0.13218 (10)	0.0203 (9)
H35A	0.221669	0.343850	0.129172	0.030*
H35B	0.204084	0.165305	0.131346	0.030*
H35C	0.371634	0.197471	0.116217	0.030*
C36	0.3881 (6)	0.2836 (6)	0.32625 (11)	0.0245 (9)
H36A	0.417588	0.316102	0.345373	0.037*
H36B	0.421315	0.164698	0.327270	0.037*
H36C	0.263635	0.330427	0.322790	0.037*
Cl5	1.18368 (14)	0.01843 (11)	0.28875 (3)	0.0237 (2)
Cl6	0.70077 (14)	0.60680 (11)	0.26920 (3)	0.0222 (2)
O5	0.6582 (4)	0.4151 (3)	0.16794 (8)	0.0231 (7)
O6	0.9707 (4)	0.3466 (3)	0.30442 (8)	0.0198 (6)
N3	0.8929 (5)	0.2097 (4)	0.18647 (9)	0.0184 (7)
H3N	0.953 (5)	0.108 (3)	0.1830 (11)	0.022*
C19	0.9015 (5)	0.2478 (4)	0.21581 (11)	0.0195 (9)
C20	0.8034 (5)	0.3936 (5)	0.22667 (11)	0.0196 (9)
H20	0.722681	0.473728	0.213786	0.024*
C21	0.8234 (5)	0.4217 (4)	0.25607 (12)	0.0194 (9)
C22	0.9444 (5)	0.3112 (4)	0.27637 (10)	0.0165 (9)
C23	1.0402 (5)	0.1646 (4)	0.26459 (11)	0.0191 (9)
C24	1.0205 (6)	0.1348 (4)	0.23504 (11)	0.0191 (9)
H24	1.089688	0.035370	0.227819	0.023*
C25	0.7743 (6)	0.2903 (5)	0.16449 (11)	0.0189 (9)
C26	0.8020 (6)	0.2120 (4)	0.13468 (11)	0.0233 (9)
H26A	0.907911	0.118589	0.135892	0.035*
H26B	0.812176	0.291635	0.118147	0.035*
H26C	0.703834	0.175306	0.130819	0.035*
C27	0.8663 (6)	0.2972 (5)	0.32811 (11)	0.0229 (9)
H27A	0.886784	0.335289	0.347283	0.034*
H27B	0.897545	0.178263	0.330323	0.034*
H27C	0.744171	0.344591	0.322689	0.034*
Cl3	0.48165 (15)	0.98228 (12)	0.04455 (3)	0.0257 (2)
Cl4	0.96522 (15)	0.39414 (11)	0.06414 (3)	0.0238 (2)
O3	1.0073 (4)	0.5849 (3)	0.16548 (8)	0.0240 (7)
O4	0.6939 (4)	0.6544 (4)	0.02870 (7)	0.0229 (7)
N2	0.7712 (5)	0.7930 (4)	0.14728 (9)	0.0166 (7)
H2N	0.679 (4)	0.871 (4)	0.1534 (11)	0.020*
C10	0.7613 (6)	0.7527 (5)	0.11650 (10)	0.0175 (8)
C11	0.8634 (6)	0.6067 (5)	0.10666 (11)	0.0197 (9)
H11	0.946091	0.529510	0.119663	0.024*
C12	0.8408 (6)	0.5766 (5)	0.07694 (10)	0.0185 (8)
C13	0.7234 (6)	0.6884 (5)	0.05729 (11)	0.0207 (9)
C14	0.6279 (6)	0.8349 (4)	0.06840 (10)	0.0180 (9)
C15	0.6435 (6)	0.8686 (5)	0.09760 (10)	0.0196 (8)
H15	0.575325	0.968817	0.104654	0.023*
C16	0.8878 (6)	0.7122 (4)	0.16864 (10)	0.0156 (8)
C17	0.8620 (5)	0.7887 (5)	0.19837 (10)	0.0187 (8)
H17A	0.781361	0.899664	0.195428	0.028*
H17B	0.972804	0.791930	0.205511	0.028*
H17C	0.814938	0.724096	0.213432	0.028*
C18	0.7998 (6)	0.7026 (6)	0.00546 (11)	0.0274 (10)
H18A	0.768863	0.678187	−0.014291	0.041*
H18B	0.921413	0.642679	0.009711	0.041*
H18C	0.780983	0.819614	0.005182	0.041*

Atomic displacement parameters (Å²) top

	U¹¹	U²²	U³³	U¹²	U¹³	U²³
Cl1	0.0279 (5)	0.0257 (4)	0.0232 (6)	−0.0036 (4)	−0.0078 (5)	−0.0002 (4)
Cl2	0.0362 (6)	0.0218 (4)	0.0170 (6)	−0.0053 (4)	0.0024 (5)	−0.0092 (4)
O1	0.0229 (15)	0.0217 (12)	0.0161 (17)	−0.0021 (11)	−0.0024 (13)	−0.0032 (11)
O2	0.0284 (16)	0.0358 (15)	0.0135 (17)	−0.0147 (13)	−0.0009 (14)	−0.0056 (12)
N1	0.0183 (16)	0.0195 (15)	0.0169 (19)	−0.0036 (12)	0.0021 (15)	−0.0048 (13)
C1	0.0210 (19)	0.0225 (18)	0.015 (2)	−0.0128 (15)	0.0048 (18)	−0.0022 (15)
C2	0.026 (2)	0.0221 (17)	0.011 (2)	−0.0093 (15)	−0.0040 (17)	−0.0052 (14)
C3	0.0176 (18)	0.0199 (17)	0.016 (2)	−0.0048 (14)	0.0006 (17)	0.0012 (15)
C4	0.026 (2)	0.0237 (18)	0.016 (2)	−0.0134 (16)	0.006 (2)	0.0021 (16)
C5	0.022 (2)	0.0201 (17)	0.012 (2)	−0.0066 (15)	0.0039 (18)	−0.0060 (15)
C6	0.027 (2)	0.0166 (16)	0.018 (2)	−0.0089 (15)	0.0017 (19)	−0.0023 (15)
C7	0.024 (2)	0.0198 (17)	0.014 (2)	−0.0110 (15)	0.0057 (18)	−0.0051 (14)
C8	0.024 (2)	0.0242 (18)	0.018 (2)	−0.0070 (15)	0.0049 (19)	−0.0008 (16)
C9	0.037 (3)	0.042 (2)	0.012 (2)	−0.010 (2)	−0.003 (2)	0.0008 (18)
Cl9	0.0207 (5)	0.0161 (4)	0.0273 (6)	−0.0012 (3)	−0.0087 (4)	−0.0006 (4)
Cl10	0.0210 (5)	0.0142 (4)	0.0221 (5)	0.0000 (3)	0.0014 (4)	−0.0070 (3)
O9	0.0182 (14)	0.0112 (11)	0.0266 (18)	0.0048 (10)	−0.0048 (13)	−0.0027 (11)
O10	0.0218 (14)	0.0219 (12)	0.0145 (16)	−0.0123 (10)	0.0005 (13)	−0.0043 (11)
N5	0.0131 (15)	0.0113 (13)	0.0188 (19)	0.0036 (11)	−0.0044 (15)	−0.0038 (12)
C37	0.0121 (17)	0.0123 (15)	0.012 (2)	−0.0034 (13)	−0.0023 (16)	−0.0005 (13)
C38	0.0099 (15)	0.0057 (14)	0.024 (2)	0.0046 (11)	0.0014 (16)	−0.0002 (13)
C39	0.0138 (17)	0.0135 (15)	0.020 (2)	−0.0057 (13)	0.0086 (16)	−0.0147 (14)
C40	0.0146 (18)	0.0171 (16)	0.017 (2)	−0.0066 (13)	0.0007 (17)	−0.0052 (14)
C41	0.0140 (17)	0.0129 (15)	0.024 (2)	−0.0057 (13)	0.0014 (18)	−0.0029 (14)
C42	0.0093 (16)	0.0075 (14)	0.026 (2)	0.0012 (12)	−0.0008 (17)	−0.0050 (14)
C43	0.0093 (17)	0.0127 (16)	0.027 (2)	−0.0007 (12)	−0.0038 (17)	0.0018 (15)
C44	0.0138 (17)	0.0175 (16)	0.021 (2)	−0.0052 (13)	0.0011 (17)	−0.0013 (14)
C45	0.022 (2)	0.0288 (19)	0.016 (2)	−0.0115 (15)	−0.0027 (18)	0.0021 (16)
Cl11	0.0167 (4)	0.0178 (4)	0.0299 (6)	0.0002 (3)	−0.0082 (4)	0.0000 (4)
Cl12	0.0236 (5)	0.0155 (4)	0.0238 (6)	−0.0008 (3)	0.0005 (4)	−0.0076 (4)
O11	0.0147 (13)	0.0116 (11)	0.0264 (17)	0.0010 (9)	0.0029 (13)	−0.0048 (11)
O12	0.0185 (14)	0.0260 (13)	0.0187 (17)	−0.0119 (10)	−0.0027 (13)	−0.0062 (12)
N6	0.0136 (15)	0.0116 (13)	0.022 (2)	−0.0012 (11)	−0.0030 (15)	−0.0036 (12)
C46	0.0123 (17)	0.0128 (15)	0.018 (2)	−0.0034 (13)	0.0018 (17)	0.0015 (14)
C47	0.0128 (17)	0.0109 (15)	0.027 (2)	−0.0028 (13)	0.0037 (18)	−0.0065 (14)
C48	0.0154 (18)	0.0159 (16)	0.021 (2)	−0.0055 (14)	−0.0032 (18)	0.0010 (15)
C49	0.0116 (17)	0.0222 (16)	0.016 (2)	−0.0094 (13)	0.0001 (17)	−0.0099 (15)
C50	0.0108 (17)	0.0163 (16)	0.023 (2)	−0.0038 (13)	0.0005 (17)	−0.0016 (15)
C51	0.0094 (16)	0.0122 (15)	0.023 (2)	−0.0002 (12)	0.0007 (16)	0.0003 (14)
C52	0.0164 (18)	0.0150 (15)	0.019 (2)	−0.0077 (13)	0.0021 (17)	−0.0038 (14)
C53	0.0190 (19)	0.0152 (16)	0.026 (3)	−0.0024 (14)	−0.0049 (18)	−0.0075 (15)
C54	0.028 (2)	0.036 (2)	0.024 (3)	−0.0177 (18)	−0.002 (2)	−0.0055 (18)
Cl7	0.0222 (5)	0.0224 (4)	0.0245 (6)	−0.0022 (3)	−0.0059 (5)	−0.0002 (4)
Cl8	0.0274 (5)	0.0204 (4)	0.0192 (5)	−0.0035 (4)	0.0008 (5)	−0.0066 (4)
O7	0.0224 (15)	0.0186 (12)	0.0172 (16)	−0.0031 (10)	0.0027 (13)	−0.0046 (11)
O8	0.0211 (15)	0.0247 (13)	0.0144 (16)	−0.0108 (11)	−0.0045 (13)	−0.0001 (11)
N4	0.0165 (15)	0.0191 (14)	0.0113 (18)	−0.0007 (12)	−0.0029 (14)	−0.0001 (12)
C28	0.0169 (18)	0.0190 (17)	0.015 (2)	−0.0075 (14)	−0.0011 (17)	−0.0092 (14)
C29	0.0120 (17)	0.0171 (17)	0.024 (2)	−0.0020 (13)	0.0023 (18)	0.0006 (15)
C30	0.0155 (18)	0.0174 (17)	0.025 (2)	−0.0084 (13)	−0.0039 (18)	−0.0043 (15)
C31	0.019 (2)	0.0195 (18)	0.016 (2)	−0.0079 (15)	−0.0039 (18)	0.0006 (15)
C32	0.022 (2)	0.0152 (16)	0.020 (2)	−0.0082 (14)	0.0042 (19)	−0.0072 (15)
C33	0.0169 (18)	0.0199 (16)	0.014 (2)	−0.0037 (14)	−0.0035 (17)	−0.0038 (15)
C34	0.0171 (18)	0.0126 (15)	0.019 (2)	−0.0034 (13)	−0.0012 (18)	0.0004 (14)
C35	0.029 (2)	0.0194 (17)	0.010 (2)	−0.0046 (15)	−0.0044 (18)	0.0001 (14)
C36	0.026 (2)	0.041 (2)	0.013 (2)	−0.0201 (18)	0.0015 (19)	−0.0015 (17)
Cl5	0.0258 (5)	0.0186 (4)	0.0227 (6)	−0.0012 (3)	−0.0089 (5)	−0.0005 (4)
Cl6	0.0263 (5)	0.0169 (4)	0.0194 (5)	−0.0003 (4)	0.0014 (4)	−0.0050 (4)
O5	0.0181 (15)	0.0247 (14)	0.0210 (18)	0.0019 (11)	−0.0035 (14)	−0.0052 (12)
O6	0.0164 (14)	0.0222 (12)	0.0224 (17)	−0.0068 (10)	−0.0013 (13)	−0.0076 (11)
N3	0.0194 (16)	0.0172 (14)	0.018 (2)	−0.0052 (12)	0.0025 (15)	−0.0040 (13)
C19	0.0163 (18)	0.0125 (16)	0.029 (3)	−0.0048 (13)	0.0002 (18)	0.0010 (15)
C20	0.020 (2)	0.0216 (18)	0.016 (2)	−0.0064 (15)	−0.0024 (18)	0.0019 (15)
C21	0.0161 (18)	0.0126 (16)	0.028 (3)	−0.0028 (13)	−0.0006 (19)	0.0007 (15)
C22	0.020 (2)	0.0189 (18)	0.014 (2)	−0.0116 (15)	0.0001 (18)	0.0008 (15)
C23	0.0153 (18)	0.0173 (16)	0.025 (2)	−0.0052 (14)	−0.0014 (18)	−0.0034 (15)
C24	0.0203 (19)	0.0150 (16)	0.023 (2)	−0.0060 (14)	−0.0003 (19)	−0.0032 (15)
C25	0.022 (2)	0.0194 (17)	0.018 (2)	−0.0107 (15)	0.0016 (18)	0.0004 (15)
C26	0.032 (2)	0.0137 (16)	0.021 (2)	−0.0026 (15)	−0.002 (2)	−0.0017 (15)
C27	0.023 (2)	0.0290 (19)	0.017 (2)	−0.0089 (16)	0.0010 (18)	−0.0025 (16)
Cl3	0.0314 (6)	0.0228 (4)	0.0197 (6)	−0.0035 (4)	−0.0083 (5)	−0.0007 (4)
Cl4	0.0329 (5)	0.0195 (4)	0.0153 (5)	−0.0024 (4)	0.0034 (4)	−0.0046 (3)
O3	0.0274 (17)	0.0233 (14)	0.0177 (17)	−0.0035 (12)	0.0027 (14)	−0.0009 (12)
O4	0.0304 (16)	0.0269 (14)	0.0128 (16)	−0.0104 (12)	−0.0027 (14)	−0.0028 (11)
N2	0.0212 (16)	0.0158 (14)	0.0116 (18)	−0.0036 (12)	0.0022 (15)	−0.0036 (12)
C10	0.0216 (19)	0.0288 (18)	0.0062 (19)	−0.0131 (15)	0.0060 (17)	−0.0066 (15)
C11	0.027 (2)	0.0235 (18)	0.012 (2)	−0.0109 (16)	0.0007 (18)	−0.0067 (15)
C12	0.024 (2)	0.0200 (17)	0.011 (2)	−0.0076 (14)	−0.0007 (17)	0.0044 (14)
C13	0.021 (2)	0.0270 (19)	0.017 (2)	−0.0120 (16)	0.0003 (19)	−0.0041 (16)
C14	0.023 (2)	0.0190 (17)	0.011 (2)	−0.0061 (14)	−0.0053 (17)	0.0049 (14)
C15	0.024 (2)	0.0223 (17)	0.012 (2)	−0.0066 (15)	0.0030 (18)	−0.0002 (15)
C16	0.0216 (19)	0.0163 (16)	0.009 (2)	−0.0056 (14)	0.0057 (16)	−0.0057 (13)
C17	0.0183 (19)	0.0306 (19)	0.007 (2)	−0.0065 (15)	−0.0039 (17)	−0.0047 (15)
C18	0.026 (2)	0.043 (2)	0.012 (2)	−0.0094 (18)	−0.0020 (19)	−0.0036 (18)

Geometric parameters (Å, º) top

Cl1—C3	1.720 (4)	Cl7—C30	1.755 (4)
Cl2—C5	1.741 (4)	Cl8—C32	1.731 (4)
O1—C7	1.244 (5)	O7—C34	1.234 (5)
O2—C4	1.348 (6)	O8—C31	1.365 (6)
O2—C9	1.447 (6)	O8—C36	1.453 (6)
N1—C7	1.356 (5)	N4—C34	1.343 (5)
N1—C1	1.412 (6)	N4—C28	1.425 (6)
N1—H1N	0.899 (17)	N4—H4N	0.901 (17)
C1—C2	1.382 (6)	C28—C29	1.391 (5)
C1—C6	1.395 (6)	C28—C33	1.395 (5)
C2—C3	1.409 (6)	C29—C30	1.365 (7)
C2—H2	0.9500	C29—H29	0.9500
C3—C4	1.410 (6)	C30—C31	1.373 (6)
C4—C5	1.392 (6)	C31—C32	1.402 (6)
C5—C6	1.373 (7)	C32—C33	1.395 (7)
C6—H6	0.9500	C33—H33	0.9500
C7—C8	1.493 (7)	C34—C35	1.505 (6)
C8—H8A	0.9800	C35—H35A	0.9800
C8—H8B	0.9800	C35—H35B	0.9800
C8—H8C	0.9800	C35—H35C	0.9800
C9—H9A	0.9800	C36—H36A	0.9800
C9—H9B	0.9800	C36—H36B	0.9800
C9—H9C	0.9800	C36—H36C	0.9800
Cl9—C41	1.728 (4)	Cl5—C23	1.735 (4)
Cl10—C39	1.733 (3)	Cl6—C21	1.749 (4)
O9—C43	1.237 (5)	O5—C25	1.213 (5)
O10—C40	1.367 (6)	O6—C22	1.350 (6)
O10—C45	1.443 (6)	O6—C27	1.453 (6)
N5—C43	1.368 (5)	N3—C25	1.370 (6)
N5—C37	1.395 (6)	N3—C19	1.383 (6)
N5—H5N	0.895 (17)	N3—H3N	0.891 (17)
C37—C38	1.410 (5)	C19—C24	1.387 (6)
C37—C42	1.417 (5)	C19—C20	1.390 (6)
C38—C39	1.393 (6)	C20—C21	1.373 (7)
C38—H38	0.9500	C20—H20	0.9500
C39—C40	1.366 (6)	C21—C22	1.413 (6)
C40—C41	1.392 (5)	C22—C23	1.408 (6)
C41—C42	1.380 (7)	C23—C24	1.384 (7)
C42—H42	0.9500	C24—H24	0.9500
C43—C44	1.487 (6)	C25—C26	1.524 (6)
C44—H44A	0.9800	C26—H26A	0.9800
C44—H44B	0.9800	C26—H26B	0.9800
C44—H44C	0.9800	C26—H26C	0.9800
C45—H45A	0.9800	C27—H27A	0.9800
C45—H45B	0.9800	C27—H27B	0.9800
C45—H45C	0.9800	C27—H27C	0.9800
Cl11—C48	1.735 (4)	Cl3—C14	1.742 (4)
Cl12—C50	1.728 (4)	Cl4—C12	1.729 (4)
O11—C52	1.228 (5)	O3—C16	1.239 (5)
O12—C49	1.376 (6)	O4—C13	1.375 (6)
O12—C54	1.429 (6)	O4—C18	1.443 (6)
N6—C52	1.358 (6)	N2—C16	1.343 (6)
N6—C46	1.391 (6)	N2—C10	1.453 (5)
N6—H6N	0.902 (17)	N2—H2N	0.894 (17)
C46—C51	1.396 (5)	C10—C11	1.382 (6)
C46—C47	1.407 (5)	C10—C15	1.384 (6)
C47—C48	1.389 (7)	C11—C12	1.397 (7)
C47—H47	0.9500	C11—H11	0.9500
C48—C49	1.398 (6)	C12—C13	1.387 (6)
C49—C50	1.388 (5)	C13—C14	1.394 (6)
C50—C51	1.377 (7)	C14—C15	1.374 (6)
C51—H51	0.9500	C15—H15	0.9500
C52—C53	1.514 (6)	C16—C17	1.513 (6)
C53—H53A	0.9800	C17—H17A	0.9800
C53—H53B	0.9800	C17—H17B	0.9800
C53—H53C	0.9800	C17—H17C	0.9800
C54—H54A	0.9800	C18—H18A	0.9800
C54—H54B	0.9800	C18—H18B	0.9800
C54—H54C	0.9800	C18—H18C	0.9800

C4—O2—C9	115.9 (4)	C31—O8—C36	114.4 (3)
C7—N1—C1	128.5 (4)	C34—N4—C28	128.0 (3)
C7—N1—H1N	121 (3)	C34—N4—H4N	114 (4)
C1—N1—H1N	110 (3)	C28—N4—H4N	117 (4)
C2—C1—C6	120.3 (4)	C29—C28—C33	119.6 (4)
C2—C1—N1	124.4 (4)	C29—C28—N4	125.6 (4)
C6—C1—N1	115.3 (4)	C33—C28—N4	114.7 (4)
C1—C2—C3	118.6 (4)	C30—C29—C28	119.1 (4)
C1—C2—H2	120.7	C30—C29—H29	120.5
C3—C2—H2	120.7	C28—C29—H29	120.5
C2—C3—C4	122.3 (4)	C29—C30—C31	124.4 (4)
C2—C3—Cl1	119.1 (3)	C29—C30—Cl7	118.1 (3)
C4—C3—Cl1	118.6 (4)	C31—C30—Cl7	117.5 (4)
O2—C4—C5	122.0 (4)	O8—C31—C30	123.7 (4)
O2—C4—C3	121.8 (4)	O8—C31—C32	120.5 (4)
C5—C4—C3	116.0 (4)	C30—C31—C32	115.6 (4)
C6—C5—C4	123.0 (4)	C33—C32—C31	122.4 (4)
C6—C5—Cl2	118.3 (3)	C33—C32—Cl8	117.9 (3)
C4—C5—Cl2	118.7 (3)	C31—C32—Cl8	119.8 (4)
C5—C6—C1	119.8 (4)	C32—C33—C28	118.8 (4)
C5—C6—H6	120.1	C32—C33—H33	120.6
C1—C6—H6	120.1	C28—C33—H33	120.6
O1—C7—N1	123.4 (4)	O7—C34—N4	123.9 (4)
O1—C7—C8	122.2 (4)	O7—C34—C35	121.9 (4)
N1—C7—C8	114.3 (4)	N4—C34—C35	114.2 (3)
C7—C8—H8A	109.5	C34—C35—H35A	109.5
C7—C8—H8B	109.5	C34—C35—H35B	109.5
H8A—C8—H8B	109.5	H35A—C35—H35B	109.5
C7—C8—H8C	109.5	C34—C35—H35C	109.5
H8A—C8—H8C	109.5	H35A—C35—H35C	109.5
H8B—C8—H8C	109.5	H35B—C35—H35C	109.5
O2—C9—H9A	109.5	O8—C36—H36A	109.5
O2—C9—H9B	109.5	O8—C36—H36B	109.5
H9A—C9—H9B	109.5	H36A—C36—H36B	109.5
O2—C9—H9C	109.5	O8—C36—H36C	109.5
H9A—C9—H9C	109.5	H36A—C36—H36C	109.5
H9B—C9—H9C	109.5	H36B—C36—H36C	109.5
C40—O10—C45	114.4 (3)	C22—O6—C27	115.0 (3)
C43—N5—C37	128.7 (3)	C25—N3—C19	128.3 (4)
C43—N5—H5N	114 (4)	C25—N3—H3N	114 (3)
C37—N5—H5N	118 (4)	C19—N3—H3N	115 (3)
N5—C37—C38	124.8 (3)	N3—C19—C24	117.2 (4)
N5—C37—C42	117.3 (3)	N3—C19—C20	124.2 (4)
C38—C37—C42	118.0 (4)	C24—C19—C20	118.6 (4)
C39—C38—C37	119.0 (3)	C21—C20—C19	119.9 (4)
C39—C38—H38	120.5	C21—C20—H20	120.1
C37—C38—H38	120.5	C19—C20—H20	120.1
C40—C39—C38	123.2 (3)	C20—C21—C22	123.5 (4)
C40—C39—Cl10	120.3 (3)	C20—C21—Cl6	119.2 (3)
C38—C39—Cl10	116.5 (3)	C22—C21—Cl6	117.2 (4)
C39—C40—O10	121.5 (3)	O6—C22—C23	122.7 (4)
C39—C40—C41	117.8 (4)	O6—C22—C21	122.4 (4)
O10—C40—C41	120.6 (4)	C23—C22—C21	114.8 (4)
C42—C41—C40	121.6 (4)	C24—C23—C22	122.1 (4)
C42—C41—Cl9	118.5 (3)	C24—C23—Cl5	120.4 (3)
C40—C41—Cl9	119.9 (4)	C22—C23—Cl5	117.5 (4)
C41—C42—C37	120.4 (3)	C23—C24—C19	121.0 (4)
C41—C42—H42	119.8	C23—C24—H24	119.5
C37—C42—H42	119.8	C19—C24—H24	119.5
O9—C43—N5	122.6 (4)	O5—C25—N3	123.6 (4)
O9—C43—C44	122.9 (4)	O5—C25—C26	122.1 (4)
N5—C43—C44	114.5 (3)	N3—C25—C26	114.3 (4)
C43—C44—H44A	109.5	C25—C26—H26A	109.5
C43—C44—H44B	109.5	C25—C26—H26B	109.5
H44A—C44—H44B	109.5	H26A—C26—H26B	109.5
C43—C44—H44C	109.5	C25—C26—H26C	109.5
H44A—C44—H44C	109.5	H26A—C26—H26C	109.5
H44B—C44—H44C	109.5	H26B—C26—H26C	109.5
O10—C45—H45A	109.5	O6—C27—H27A	109.5
O10—C45—H45B	109.5	O6—C27—H27B	109.5
H45A—C45—H45B	109.5	H27A—C27—H27B	109.5
O10—C45—H45C	109.5	O6—C27—H27C	109.5
H45A—C45—H45C	109.5	H27A—C27—H27C	109.5
H45B—C45—H45C	109.5	H27B—C27—H27C	109.5
C49—O12—C54	115.3 (3)	C13—O4—C18	114.1 (4)
C52—N6—C46	129.3 (3)	C16—N2—C10	127.8 (3)
C52—N6—H6N	113 (4)	C16—N2—H2N	117 (3)
C46—N6—H6N	117 (4)	C10—N2—H2N	115 (3)
N6—C46—C51	116.4 (3)	C11—C10—C15	121.9 (4)
N6—C46—C47	124.7 (4)	C11—C10—N2	121.9 (4)
C51—C46—C47	118.8 (4)	C15—C10—N2	116.2 (4)
C48—C47—C46	119.1 (3)	C10—C11—C12	117.8 (4)
C48—C47—H47	120.4	C10—C11—H11	121.1
C46—C47—H47	120.4	C12—C11—H11	121.1
C47—C48—C49	122.2 (4)	C13—C12—C11	122.3 (4)
C47—C48—Cl11	118.7 (3)	C13—C12—Cl4	118.9 (4)
C49—C48—Cl11	119.0 (4)	C11—C12—Cl4	118.8 (3)
O12—C49—C50	121.6 (4)	O4—C13—C12	122.1 (4)
O12—C49—C48	120.9 (4)	O4—C13—C14	120.8 (4)
C50—C49—C48	117.4 (4)	C12—C13—C14	117.0 (4)
C51—C50—C49	121.8 (4)	C15—C14—C13	122.7 (4)
C51—C50—Cl12	118.6 (3)	C15—C14—Cl3	118.1 (3)
C49—C50—Cl12	119.6 (3)	C13—C14—Cl3	119.2 (4)
C50—C51—C46	120.6 (3)	C14—C15—C10	118.3 (4)
C50—C51—H51	119.7	C14—C15—H15	120.8
C46—C51—H51	119.7	C10—C15—H15	120.8
O11—C52—N6	122.9 (4)	O3—C16—N2	125.1 (4)
O11—C52—C53	121.6 (4)	O3—C16—C17	120.7 (4)
N6—C52—C53	115.4 (3)	N2—C16—C17	114.2 (3)
C52—C53—H53A	109.5	C16—C17—H17A	109.5
C52—C53—H53B	109.5	C16—C17—H17B	109.5
H53A—C53—H53B	109.5	H17A—C17—H17B	109.5
C52—C53—H53C	109.5	C16—C17—H17C	109.5
H53A—C53—H53C	109.5	H17A—C17—H17C	109.5
H53B—C53—H53C	109.5	H17B—C17—H17C	109.5
O12—C54—H54A	109.5	O4—C18—H18A	109.5
O12—C54—H54B	109.5	O4—C18—H18B	109.5
H54A—C54—H54B	109.5	H18A—C18—H18B	109.5
O12—C54—H54C	109.5	O4—C18—H18C	109.5
H54A—C54—H54C	109.5	H18A—C18—H18C	109.5
H54B—C54—H54C	109.5	H18B—C18—H18C	109.5

C7—N1—C1—C2	10.9 (7)	C34—N4—C28—C29	−12.4 (7)
C7—N1—C1—C6	−169.0 (4)	C34—N4—C28—C33	169.7 (4)
C6—C1—C2—C3	−0.7 (7)	C33—C28—C29—C30	−0.9 (7)
N1—C1—C2—C3	179.5 (4)	N4—C28—C29—C30	−178.6 (4)
C1—C2—C3—C4	1.1 (7)	C28—C29—C30—C31	−1.8 (7)
C1—C2—C3—Cl1	−178.5 (3)	C28—C29—C30—Cl7	179.3 (3)
C9—O2—C4—C5	−92.2 (5)	C36—O8—C31—C30	−91.2 (5)
C9—O2—C4—C3	93.1 (5)	C36—O8—C31—C32	93.0 (5)
C2—C3—C4—O2	173.9 (4)	C29—C30—C31—O8	−173.8 (4)
Cl1—C3—C4—O2	−6.5 (6)	Cl7—C30—C31—O8	5.0 (6)
C2—C3—C4—C5	−1.1 (7)	C29—C30—C31—C32	2.1 (7)
Cl1—C3—C4—C5	178.5 (3)	Cl7—C30—C31—C32	−179.0 (3)
O2—C4—C5—C6	−174.3 (4)	O8—C31—C32—C33	176.3 (4)
C3—C4—C5—C6	0.7 (7)	C30—C31—C32—C33	0.2 (7)
O2—C4—C5—Cl2	3.4 (6)	O8—C31—C32—Cl8	−4.5 (6)
C3—C4—C5—Cl2	178.4 (3)	C30—C31—C32—Cl8	179.3 (3)
C4—C5—C6—C1	−0.3 (7)	C31—C32—C33—C28	−2.7 (7)
Cl2—C5—C6—C1	−178.0 (3)	Cl8—C32—C33—C28	178.1 (3)
C2—C1—C6—C5	0.3 (7)	C29—C28—C33—C32	3.0 (7)
N1—C1—C6—C5	−179.9 (4)	N4—C28—C33—C32	−179.0 (4)
C1—N1—C7—O1	−0.4 (7)	C28—N4—C34—O7	1.6 (7)
C1—N1—C7—C8	178.7 (4)	C28—N4—C34—C35	−177.2 (4)
C43—N5—C37—C38	8.3 (7)	C25—N3—C19—C24	171.5 (4)
C43—N5—C37—C42	−171.2 (4)	C25—N3—C19—C20	−10.9 (7)
N5—C37—C38—C39	179.2 (4)	N3—C19—C20—C21	−178.7 (4)
C42—C37—C38—C39	−1.3 (6)	C24—C19—C20—C21	−1.2 (6)
C37—C38—C39—C40	0.0 (6)	C19—C20—C21—C22	2.1 (7)
C37—C38—C39—Cl10	−178.8 (3)	C19—C20—C21—Cl6	179.2 (3)
C38—C39—C40—O10	−174.3 (4)	C27—O6—C22—C23	−91.1 (5)
Cl10—C39—C40—O10	4.5 (6)	C27—O6—C22—C21	91.7 (5)
C38—C39—C40—C41	0.9 (6)	C20—C21—C22—O6	174.9 (4)
Cl10—C39—C40—C41	179.6 (3)	Cl6—C21—C22—O6	−2.3 (6)
C45—O10—C40—C39	−92.3 (5)	C20—C21—C22—C23	−2.5 (7)
C45—O10—C40—C41	92.7 (5)	Cl6—C21—C22—C23	−179.7 (3)
C39—C40—C41—C42	−0.4 (6)	O6—C22—C23—C24	−175.2 (4)
O10—C40—C41—C42	174.8 (4)	C21—C22—C23—C24	2.2 (6)
C39—C40—C41—Cl9	178.7 (3)	O6—C22—C23—Cl5	5.8 (6)
O10—C40—C41—Cl9	−6.1 (6)	C21—C22—C23—Cl5	−176.8 (3)
C40—C41—C42—C37	−0.9 (6)	C22—C23—C24—C19	−1.5 (7)
Cl9—C41—C42—C37	179.9 (3)	Cl5—C23—C24—C19	177.4 (3)
N5—C37—C42—C41	−178.7 (4)	N3—C19—C24—C23	178.6 (4)
C38—C37—C42—C41	1.8 (6)	C20—C19—C24—C23	1.0 (7)
C37—N5—C43—O9	0.1 (7)	C19—N3—C25—O5	2.3 (7)
C37—N5—C43—C44	179.5 (4)	C19—N3—C25—C26	−178.9 (4)
C52—N6—C46—C51	−168.7 (4)	C16—N2—C10—C11	9.2 (7)
C52—N6—C46—C47	12.2 (7)	C16—N2—C10—C15	−171.0 (4)
N6—C46—C47—C48	179.7 (4)	C15—C10—C11—C12	−1.8 (7)
C51—C46—C47—C48	0.7 (6)	N2—C10—C11—C12	178.0 (4)
C46—C47—C48—C49	0.6 (7)	C10—C11—C12—C13	1.2 (7)
C46—C47—C48—Cl11	−179.0 (3)	C10—C11—C12—Cl4	−179.3 (3)
C54—O12—C49—C50	−90.5 (5)	C18—O4—C13—C12	−92.0 (5)
C54—O12—C49—C48	93.6 (5)	C18—O4—C13—C14	91.8 (5)
C47—C48—C49—O12	174.5 (4)	C11—C12—C13—O4	−175.9 (4)
Cl11—C48—C49—O12	−6.0 (6)	Cl4—C12—C13—O4	4.7 (6)
C47—C48—C49—C50	−1.7 (6)	C11—C12—C13—C14	0.4 (7)
Cl11—C48—C49—C50	177.9 (3)	Cl4—C12—C13—C14	−179.0 (4)
O12—C49—C50—C51	−174.6 (4)	O4—C13—C14—C15	174.8 (4)
C48—C49—C50—C51	1.5 (6)	C12—C13—C14—C15	−1.6 (7)
O12—C49—C50—Cl12	2.6 (6)	O4—C13—C14—Cl3	−5.0 (6)
C48—C49—C50—Cl12	178.7 (3)	C12—C13—C14—Cl3	178.6 (4)
C49—C50—C51—C46	−0.3 (7)	C13—C14—C15—C10	1.1 (7)
Cl12—C50—C51—C46	−177.5 (3)	Cl3—C14—C15—C10	−179.1 (3)
N6—C46—C51—C50	−180.0 (4)	C11—C10—C15—C14	0.7 (7)
C47—C46—C51—C50	−0.8 (6)	N2—C10—C15—C14	−179.1 (4)
C46—N6—C52—O11	−2.7 (7)	C10—N2—C16—O3	−1.3 (7)
C46—N6—C52—C53	179.1 (4)	C10—N2—C16—C17	179.4 (4)

Hydrogen-bond geometry (Å, º) top

D—H···A	D—H	H···A	D···A	D—H···A
N1—H1N···O5	0.90 (2)	2.08 (2)	2.932 (4)	158 (4)
C2—H2···O1	0.95	2.29	2.885 (5)	120
C6—H6···O5	0.95	2.63	3.406 (6)	140
C8—H8B···Cl8	0.98	2.92	3.842 (5)	157
C9—H9B···O4	0.98	2.52	3.437 (6)	157
N5—H5N···O11ⁱ	0.90 (2)	2.03 (2)	2.922 (4)	174 (5)
C38—H38···O9	0.95	2.29	2.878 (6)	120
C44—H44C···Cl10ⁱⁱ	0.98	2.90	3.780 (5)	150
C45—H45B···O12	0.98	2.46	3.312 (5)	146
N6—H6N···O9ⁱⁱⁱ	0.90 (2)	2.04 (2)	2.933 (4)	172 (5)
C47—H47···O11	0.95	2.32	2.899 (6)	118
C51—H51···O9ⁱⁱⁱ	0.95	2.63	3.409 (5)	139
C53—H53B···Cl12ⁱⁱⁱ	0.98	2.89	3.829 (5)	161
C53—H53C···O11^iv	0.98	2.71	3.291 (5)	119
C54—H54B···O10^v	0.98	2.59	3.443 (6)	145
N4—H4N···O3^vi	0.90 (2)	2.03 (2)	2.924 (4)	170 (5)
C29—H29···O7	0.95	2.34	2.915 (6)	118
C33—H33···O3^vi	0.95	2.61	3.389 (5)	140
C35—H35B···O1^vii	0.98	2.57	3.311 (5)	133
C36—H36C···O6^vi	0.98	2.51	3.438 (6)	157
N3—H3N···O1^viii	0.89 (2)	2.08 (2)	2.910 (4)	155 (4)
C20—H20···O5	0.95	2.26	2.862 (6)	120
C26—H26A···O1^viii	0.98	2.51	3.393 (5)	150
C26—H26B···Cl4	0.98	2.87	3.771 (5)	154
C26—H26C···O7	0.98	2.57	3.291 (6)	131
C27—H27A···Cl10	0.98	2.97	3.604 (5)	123
C27—H27C···O8	0.98	2.39	3.304 (6)	154
N2—H2N···O7^ix	0.89 (2)	2.02 (2)	2.900 (4)	169 (4)
C11—H11···O3	0.95	2.24	2.860 (6)	122
C17—H17A···O7^ix	0.98	2.56	3.391 (5)	143
C17—H17C···Cl6	0.98	2.83	3.772 (5)	162
C18—H18B···O2^v	0.98	2.47	3.319 (6)	144

Symmetry codes: (i) −x+1, −y+2, −z+1; (ii) −x+1, −y+1, −z+1; (iii) −x+2, −y+1, −z+1; (iv) −x+2, −y+2, −z+1; (v) x+1, y, z; (vi) x−1, y, z; (vii) x, y−1, z; (viii) x+1, y−1, z; (ix) x, y+1, z.

Funding information

This work was supported by the U.S. Department of Education (grant No. P031B040030; Title III, Part B: Strengthening Historically Black Graduate Institutions) and the National Science Foundation (grant No. 2418415; RII FEC: Advancing Climate Neutrality in Farming Communities through Upcycling Natural Fiber–Reinforced Fireproof Vitrimer Composites). The diffractometer was acquired with support from an NSF MRI award (CHE–2215262). The authors are solely responsible for the content of this publication, which does not necessarily represent the official views of the NSF or the U.S. Department of Education.

References

Acero, J. L., Benitez, F. J., Real, F. J. & Roldan, G. (2010). Water Res. 44, 4158–4170. CrossRef CAS PubMed Google Scholar
Bai, S. V., Mensah, P. F., Li, G., Fronczek, F. R. & Uppu, R. M. (2026). CSD Communication (CCDC 2536293). CCDC, Cambridge, England. Google Scholar
Bruker (2016). APEX5 and SAINT. Bruker AXS Inc., Madison, Wisconsin, USA. Google Scholar
Buechter, M. & Gerken, G. (2022). J. Personalized Med. 12, 1657. Web of Science CrossRef Google Scholar
Gairing, S. J., Kuchen, R., Müller, L., Cankaya, A., Weerts, J., Kapucu, A., Sachse, S., Zimpel, C., Stoehr, F., Pitton, M. B., Mittler, J., Straub, B. K., Marquardt, J. U., Schattenberg, J. M., Labenz, C., Kloeckner, R., Weinmann, A., Galle, P. R., Wörns, M. A. & Foerster, F. (2022). Clin. Transl. Gastroenterol. 13, e00529. Web of Science CrossRef PubMed Google Scholar
Groom, C. R., Bruno, I. J., Lightfoot, M. P. & Ward, S. C. (2016). Acta Cryst. B72, 171–179. Web of Science CrossRef IUCr Journals Google Scholar
Hines, J. E., Agu, O. A., Deere, C. J., Bai, S. V. & Uppu, R. M. (2026). Spring 2026 National Meeting of the American Chemical Society, Atlanta, GA, USA, 22–26 March 2026. Abstract No. 4417027. American Chemical Society, Washington, DC. Google Scholar
Hines, J. E. III, Deere, C. J., Agu, O. A. & Uppu, R. M. (2025). Toxicol. Sci. 204 (S2), 218–219. Google Scholar
Krause, L., Herbst-Irmer, R., Sheldrick, G. M. & Stalke, D. (2015). J. Appl. Cryst. 48, 3–10. Web of Science CSD CrossRef ICSD CAS IUCr Journals Google Scholar
Macrae, C. F., Sovago, I., Cottrell, S. J., Galek, P. T. A., McCabe, P., Pidcock, E., Platings, M., Shields, G. P., Stevens, J. S., Towler, M. & Wood, P. A. (2020). J. Appl. Cryst. 53, 226–235. Web of Science CrossRef CAS IUCr Journals Google Scholar
Merck (1899). Merck's Manual of the Materia Medica, 1st ed. New York: Merck & Co. Google Scholar
Santol, J., Ammann, M., Reese, T., Kern, A. E., Laferl, V., Oldhafer, F., Dong, Y., Rumpf, B., Vali, M., Wiemann, B., Ortmayr, G., Brunner, S. E., Probst, J., Aiad, M., Jankoschek, A. S., Gramberger, M., Tschoegl, M. M., Salem, M., Surci, N., Thonhauser, R., Mazari, V., Hoblaj, T., Thalhammer, S., Schmelzle, M., Oldhafer, K. J., Gruenberger, T. & Starlinger, P. (2024). Eur. J. Surg. Oncol. 50, 108048. Web of Science CrossRef PubMed Google Scholar
Sheldrick, G. M. (2015a). Acta Cryst. A71, 3–8. Web of Science CrossRef IUCr Journals Google Scholar
Sheldrick, G. M. (2015b). Acta Cryst. C71, 3–8. Web of Science CrossRef IUCr Journals Google Scholar
Uppu, R. M. & Fronczek, F. R. (2026a). IUCrData 11, x260075. Google Scholar
Uppu, R. M. & Fronczek, F. R. (2026b). Toxicol. Sci. 210 (S1), 544–545. Google Scholar
Westrip, S. P. (2010). J. Appl. Cryst. 43, 920–925. Web of Science CrossRef CAS IUCr Journals Google Scholar

This is an open-access article distributed under the terms of the Creative Commons Attribution (CC-BY) Licence, which permits unrestricted use, distribution, and reproduction in any medium, provided the original authors and source are cited.
