1-(4-Methyl­benzene­sulfon­yl)-1-phenyl-1H,2H-cyclo­buta[c]quinoline

Schollmeyer, D.; Dassonneville, B.; Detert, H.

doi:10.1107/S2414314625010193

organic compounds

IUCrDATA

ISSN: 2414-3146

Volume 10| Part 11| November 2025| x251019

https://doi.org/10.1107/S2414314625010193

Open

access

1-(4-Methylbenzenesulfonyl)-1-phenyl-1H,2H-cyclobuta[c]quinoline

Dieter Schollmeyer,^a Benjamin Dassonneville ^b and Heiner Detert ^a ^*

^aUniversity Mainz, Duesbergweg 10-14, 55099 Mainz, Germany, and ^bUniversity of Mainz, Department of Chemistry, Duesbergweg 10-14, 55099 Mainz, Germany
^*Correspondence e-mail: [email protected]

Edited by M. Bolte, Goethe-Universität Frankfurt, Germany (Received 12 November 2025; accepted 13 November 2025; online 28 November 2025)

The title compound, C₂₄H₁₉NO₂S, forms strands along the b-axis direction via hydrogen bonds from the tolyl group to the sulfonyl oxygen atoms. The tricyclic framework is almost planar and the two six-membered aromatic substituents are nearly coparallel.

Keywords: crystal structure; hydrogen bridge; heterocycle; cyclobutene; 2 + 2 cycloaddition; 1,5-sulfonyl shift.

CCDC reference: 2502744

Structure description

The title compound, C₂₄H₁₉NO₂S (Fig. 1), was prepared in a larger project on indolo-annulated heterocycles (Dassonneville et al., 2023 ; Limbach et al., 2018 ; Letessier et al., 2013 ). It is an isomer and follow-up product of the recently reported N-propargyl-N-tosylaminotolane (Dassonneville et al., 2025 ). The cyclobutene ring and the quinoline system include a dihedral angle of 5.04 (9)°, C11 [0.159 (2) Å] and C12 [0.026 (2) Å] lie below the quinoline plane. The interplanar angle between the quinoline system and the phenyl ring is 57.42 (6)°, the latter is almost parallel to the tolyl unit. The interplanar angle is only 6.03 (7)°. The bond angles in the cyclobutene unit are larger at the sp³-carbon atoms (C11—C3—C4: 94.75 (13)°, C3—C4—C12: 93.72 (13)° than on the sp²-carbon atoms: C4—C12—C11: 86.19 (11)° and C12—C11—C3: 85.29 (11)°. The crystal packing features chains along the b-axis direction. The molecules are connected via hydrogen bonds (Table 1, Fig. 2) from the tolyl ring to the sulfonyl O atom, lengths are H23⋯O2: 2.52 Å and H24⋯O1: 2.47 Å, angles are C23—H23⋯O2: 161° and C24—H24⋯O1: 137°. A twofold screw axis ralates the molecules geometrically.

Table 1
Hydrogen-bond geometry (Å, °)

D—H⋯A	D—H	H⋯A	D⋯A	D—H⋯A
C23—H23⋯O2ⁱ	0.95	2.52	3.431 (2)	161
C24—H24⋯O1ⁱ	0.95	2.47	3.2357 (19)	137
Symmetry code: (i) $[-x+{\script{3\over 2}}, y-{\script{1\over 2}}, -z+{\script{1\over 2}}]$ .

Figure 1
View the title compound. Displacement ellipsoids are drawn at the 50% probability level.

Figure 2
Part of the packing diagram. View along the a-axis direction. Hydrogen bonds are shown as dashed lines.

Synthesis and crystallization

The title compound, C₂₄H₁₉NO₂S, appeared as by-product in low yield in the propargylation of 2-tosylaminotolane (Dassonneville et al., 2025). A possible mechanistic pathway is given in Fig. 3. A base-catalyzed isomerization of the propargyl unit to an allenyl substituent followed by 2 + 2 cycloaddition of the outer double bond of the allene with the tolane triple bond generates a cyclobutene with concomitant closure of the quinoline ring. A supra-suprafacial 1,5-shift of the sulfonyl group from quinoline-N to a cyclobutene ring with aromatization of the pyridine ring gives the final compound. The compound crystallized from toluene solution as brownish crystals with m.p. = 426 K. The annotation of NMR signals follows IUPAC nomenclature. ¹H-NMR (400 MHz, CDCl₃): 8.66 (s, 1 H, 2-H quin); 8.20 (dd, J = 8 Hz, J′= 4 Hz), 8.16 (dd, J = 8 Hz, J′= 4 Hz) (5-H, 8-H quin), 7.80 (ddd, 1 H), 7.74 (ddd, 1 H) (6-H, 7-H, quin), 7.67–7.63 (m, 2 H, ph), 7.42–7.35 (m, 5 H, ph + tol), 7.09 (d, 2 H, 3-H, 5-H, tol), 4.20 (d, J = 16 Hz, CH₂), 3.77 (d, J = 16 Hz, CH₂), 2.37 (s, 3 H, CH₃). ¹³C-NMR (100 MHz, CDCl₃): 147.09 (C_q), 147.32 (C_q), 145.27 (C_q), 144.75 (CH, C-2 quin), 136.44 (C_q), 132.96 (C_q), 132.32 (C_q), 131.28 (CH, C-6 or C-7 quin), 130.11 (2 CH), 130.08 (2 CH), 129.22 (CH), 129.19 (2 CH), 129.02 (CH), 128.52 (CH), 128.32 (2 CH), 124.33 (CH, C-7 or C-6 quin), 123.97 (C_q), 78.96 (C_q), 42.26 (CH₂), 21.66 (CH₃).

Figure 3
Possible synthetic mechanism.

Refinement

Crystal data, data collection and structure refinement details are summarized in Table 2.

Table 2
Experimental details

Crystal data
Chemical formula	C₂₄H₁₉NO₂S
M_r	385.46
Crystal system, space group	Monoclinic, P2₁/n
Temperature (K)	120
a, b, c (Å)	7.5268 (3), 12.0672 (7), 20.6402 (9)
β (°)	92.740 (3)
V (Å³)	1872.55 (16)
Z	4
Radiation type	Mo Kα
μ (mm⁻¹)	0.19
Crystal size (mm)	0.44 × 0.36 × 0.18

Data collection
Diffractometer	STOE IPDS 2T
Absorption correction	Integration (X-RED3; Stoe & Cie, 2020 )
T_min, T_max	0.933, 0.979
No. of measured, independent and observed [I > 2σ(I)] reflections	9143, 4455, 3856
R_int	0.022
(sin θ/λ)_max (Å⁻¹)	0.660

Refinement
R[F² > 2σ(F²)], wR(F²), S	0.042, 0.109, 1.08
No. of reflections	4455
No. of parameters	254
H-atom treatment	H-atom parameters constrained
Δρ_max, Δρ_min (e Å⁻³)	0.49, −0.38
Computer programs 2.5.18.0 (Stoe & Cie, 2020), SHELXT2014 (Sheldrick, 2015a ), SHELXL2019/2 (Sheldrick, 2015b ) and PLATON (Spek, 2009 ).

Structural data

CCDC reference: 2502744

Crystal structure: contains datablocks I, global. DOI: https://doi.org/10.1107/S2414314625010193/bt4189sup1.cif

Structure factors: contains datablock I. DOI: https://doi.org/10.1107/S2414314625010193/bt4189Isup2.hkl

Supporting information file. DOI: https://doi.org/10.1107/S2414314625010193/bt4189Isup3.cml

checkCIF report

Computing details top

1-(4-Methylbenzenesulfonyl)-1-phenyl-1H,2H-cyclobuta[c]quinoline top

Crystal data top

C₂₄H₁₉NO₂S	F(000) = 808
M_r = 385.46	D_x = 1.367 Mg m⁻³
Monoclinic, P2₁/n	Mo Kα radiation, λ = 0.71073 Å
a = 7.5268 (3) Å	Cell parameters from 12708 reflections
b = 12.0672 (7) Å	θ = 2.6–28.4°
c = 20.6402 (9) Å	µ = 0.19 mm⁻¹
β = 92.740 (3)°	T = 120 K
V = 1872.55 (16) Å³	Block, colorless
Z = 4	0.44 × 0.36 × 0.18 mm

Data collection top

STOE IPDS 2T diffractometer	3856 reflections with I > 2σ(I)
Detector resolution: 6.67 pixels mm^-1	R_int = 0.022
rotation method, ω scans	θ_max = 28.0°, θ_min = 2.6°
Absorption correction: integration (X-Red3; Stoe & Cie, 2020)	h = −9→9
T_min = 0.933, T_max = 0.979	k = −13→15
9143 measured reflections	l = −23→27
4455 independent reflections

Refinement top

Refinement on F²	Primary atom site location: dual
Least-squares matrix: full	Hydrogen site location: inferred from neighbouring sites
R[F² > 2σ(F²)] = 0.042	H-atom parameters constrained
wR(F²) = 0.109	w = 1/[σ²(F_o²) + (0.0478P)² + 1.4388P] where P = (F_o² + 2F_c²)/3
S = 1.08	(Δ/σ)_max = 0.001
4455 reflections	Δρ_max = 0.49 e Å⁻³
254 parameters	Δρ_min = −0.38 e Å⁻³
0 restraints

Special details top

Geometry. All esds (except the esd in the dihedral angle between two l.s. planes) are estimated using the full covariance matrix. The cell esds are taken into account individually in the estimation of esds in distances, angles and torsion angles; correlations between esds in cell parameters are only used when they are defined by crystal symmetry. An approximate (isotropic) treatment of cell esds is used for estimating esds involving l.s. planes.

Refinement. Hydrogen atoms were placed at calculated positions and were refined in the riding-model approximation with C_aromatic–H = 0.95 Å, C_methyl–H = 0.98 Å, C_methylene–H = 0.99 Å, and with U_iso(H) = 1.2 U_eq(C) for aromatic and methylene H atoms and with U_iso(H) = 1.5 U_eq(C_methyl). The methyl group was allowed to rotate but not to tip.

Fractional atomic coordinates and isotropic or equivalent isotropic displacement parameters (Å²) top

	x	y	z	U_iso*/U_eq
S1	0.64207 (5)	0.46384 (3)	0.25290 (2)	0.01500 (11)
O1	0.63964 (16)	0.57122 (9)	0.22241 (5)	0.0202 (2)
N1	0.2289 (2)	0.16806 (12)	0.36221 (7)	0.0245 (3)
O2	0.80565 (15)	0.42439 (10)	0.28432 (5)	0.0199 (2)
C2	0.1616 (2)	0.25542 (14)	0.33105 (8)	0.0228 (3)
H2	0.039969	0.255983	0.316417	0.027*
C3	0.2704 (2)	0.34742 (14)	0.31963 (7)	0.0187 (3)
C4	0.4442 (2)	0.34911 (13)	0.34160 (7)	0.0165 (3)
C5	0.5253 (2)	0.25768 (13)	0.37323 (7)	0.0172 (3)
C6	0.7067 (2)	0.24665 (13)	0.39355 (7)	0.0190 (3)
H6	0.786202	0.306822	0.388467	0.023*
C7	0.7677 (2)	0.14939 (14)	0.42053 (8)	0.0231 (3)
H7	0.890248	0.141725	0.433003	0.028*
C8	0.6503 (3)	0.06065 (15)	0.42992 (8)	0.0267 (4)
H8	0.694212	−0.005968	0.449289	0.032*
C9	0.4743 (3)	0.06914 (14)	0.41153 (8)	0.0258 (4)
H9	0.396757	0.008686	0.418641	0.031*
C10	0.4059 (2)	0.16729 (13)	0.38190 (8)	0.0203 (3)
C11	0.2768 (2)	0.46028 (13)	0.28729 (8)	0.0190 (3)
H11A	0.198639	0.516693	0.305973	0.023*
H11B	0.262576	0.458325	0.239374	0.023*
C12	0.4775 (2)	0.46404 (12)	0.31482 (7)	0.0156 (3)
C13	0.5228 (2)	0.55765 (13)	0.36154 (7)	0.0164 (3)
C14	0.4825 (2)	0.66637 (14)	0.34362 (8)	0.0206 (3)
H14	0.427011	0.681116	0.302206	0.025*
C15	0.5227 (2)	0.75340 (14)	0.38585 (9)	0.0242 (3)
H15	0.497528	0.827501	0.372878	0.029*
C16	0.5998 (2)	0.73204 (15)	0.44701 (8)	0.0249 (4)
H16	0.625610	0.791420	0.476187	0.030*
C17	0.6390 (2)	0.62422 (15)	0.46546 (8)	0.0216 (3)
H17	0.691211	0.609713	0.507426	0.026*
C18	0.6024 (2)	0.53691 (13)	0.42282 (8)	0.0183 (3)
H18	0.631596	0.463158	0.435420	0.022*
C19	0.5675 (2)	0.36514 (13)	0.19515 (7)	0.0156 (3)
C20	0.4723 (2)	0.40126 (13)	0.13940 (8)	0.0191 (3)
H20	0.446551	0.477642	0.132914	0.023*
C21	0.4162 (2)	0.32307 (14)	0.09379 (8)	0.0208 (3)
H21	0.351596	0.346458	0.055557	0.025*
C22	0.4529 (2)	0.21033 (14)	0.10284 (8)	0.0188 (3)
C23	0.5476 (2)	0.17718 (13)	0.15898 (8)	0.0182 (3)
H23	0.572953	0.100793	0.165659	0.022*
C24	0.6058 (2)	0.25370 (13)	0.20536 (8)	0.0174 (3)
H24	0.670775	0.230324	0.243521	0.021*
C25	0.3904 (2)	0.12684 (15)	0.05270 (8)	0.0255 (4)
H25A	0.443051	0.143849	0.011332	0.038*
H25B	0.260469	0.129811	0.047153	0.038*
H25C	0.427041	0.052451	0.066930	0.038*

Atomic displacement parameters (Å²) top

	U¹¹	U²²	U³³	U¹²	U¹³	U²³
S1	0.01716 (18)	0.01263 (18)	0.01518 (18)	−0.00107 (13)	0.00034 (13)	−0.00060 (13)
O1	0.0275 (6)	0.0139 (5)	0.0194 (5)	−0.0026 (4)	0.0024 (4)	0.0008 (4)
N1	0.0271 (7)	0.0199 (7)	0.0269 (7)	−0.0069 (6)	0.0049 (6)	−0.0025 (6)
O2	0.0176 (5)	0.0206 (6)	0.0213 (5)	−0.0007 (4)	−0.0014 (4)	−0.0010 (5)
C2	0.0201 (8)	0.0236 (8)	0.0249 (8)	−0.0050 (6)	0.0026 (6)	−0.0039 (7)
C3	0.0200 (7)	0.0185 (8)	0.0178 (7)	−0.0012 (6)	0.0023 (6)	−0.0030 (6)
C4	0.0201 (7)	0.0146 (7)	0.0149 (7)	−0.0022 (6)	0.0033 (5)	−0.0015 (5)
C5	0.0234 (8)	0.0146 (7)	0.0139 (7)	−0.0017 (6)	0.0031 (6)	−0.0019 (5)
C6	0.0247 (8)	0.0170 (7)	0.0156 (7)	−0.0005 (6)	0.0013 (6)	−0.0008 (6)
C7	0.0295 (9)	0.0222 (8)	0.0176 (7)	0.0048 (7)	0.0011 (6)	−0.0007 (6)
C8	0.0413 (10)	0.0173 (8)	0.0218 (8)	0.0044 (7)	0.0044 (7)	0.0028 (6)
C9	0.0387 (10)	0.0141 (8)	0.0251 (8)	−0.0047 (7)	0.0067 (7)	−0.0005 (6)
C10	0.0292 (8)	0.0149 (7)	0.0172 (7)	−0.0032 (6)	0.0053 (6)	−0.0029 (6)
C11	0.0167 (7)	0.0191 (8)	0.0212 (7)	0.0006 (6)	−0.0008 (6)	−0.0014 (6)
C12	0.0166 (7)	0.0136 (7)	0.0165 (7)	0.0007 (5)	0.0010 (5)	0.0003 (6)
C13	0.0169 (7)	0.0153 (7)	0.0173 (7)	−0.0017 (5)	0.0031 (5)	−0.0015 (6)
C14	0.0236 (8)	0.0172 (8)	0.0213 (7)	0.0020 (6)	0.0030 (6)	0.0007 (6)
C15	0.0281 (9)	0.0146 (8)	0.0305 (9)	0.0007 (6)	0.0074 (7)	−0.0010 (7)
C16	0.0281 (9)	0.0221 (9)	0.0251 (8)	−0.0061 (7)	0.0071 (7)	−0.0094 (7)
C17	0.0225 (8)	0.0245 (8)	0.0181 (7)	−0.0044 (6)	0.0032 (6)	−0.0025 (6)
C18	0.0197 (7)	0.0164 (7)	0.0189 (7)	−0.0012 (6)	0.0025 (6)	−0.0002 (6)
C19	0.0169 (7)	0.0144 (7)	0.0157 (7)	−0.0003 (5)	0.0008 (5)	−0.0021 (6)
C20	0.0223 (8)	0.0152 (7)	0.0195 (7)	0.0013 (6)	−0.0008 (6)	0.0010 (6)
C21	0.0235 (8)	0.0210 (8)	0.0176 (7)	0.0029 (6)	−0.0036 (6)	0.0001 (6)
C22	0.0165 (7)	0.0199 (8)	0.0201 (7)	−0.0009 (6)	0.0019 (6)	−0.0040 (6)
C23	0.0177 (7)	0.0144 (7)	0.0226 (7)	0.0009 (5)	0.0024 (6)	−0.0012 (6)
C24	0.0176 (7)	0.0167 (7)	0.0178 (7)	0.0021 (5)	0.0004 (5)	0.0009 (6)
C25	0.0262 (8)	0.0250 (9)	0.0247 (8)	0.0000 (7)	−0.0035 (7)	−0.0083 (7)

Geometric parameters (Å, º) top

S1—O1	1.4402 (12)	C13—C14	1.393 (2)
S1—O2	1.4446 (11)	C13—C18	1.396 (2)
S1—C19	1.7579 (15)	C14—C15	1.389 (2)
S1—C12	1.8219 (15)	C14—H14	0.9500
N1—C2	1.323 (2)	C15—C16	1.388 (3)
N1—C10	1.374 (2)	C15—H15	0.9500
C2—C3	1.406 (2)	C16—C17	1.384 (2)
C2—H2	0.9500	C16—H16	0.9500
C3—C4	1.364 (2)	C17—C18	1.392 (2)
C3—C11	1.518 (2)	C17—H17	0.9500
C4—C5	1.406 (2)	C18—H18	0.9500
C4—C12	1.518 (2)	C19—C24	1.389 (2)
C5—C6	1.415 (2)	C19—C20	1.396 (2)
C5—C10	1.430 (2)	C20—C21	1.384 (2)
C6—C7	1.369 (2)	C20—H20	0.9500
C6—H6	0.9500	C21—C22	1.399 (2)
C7—C8	1.408 (3)	C21—H21	0.9500
C7—H7	0.9500	C22—C23	1.390 (2)
C8—C9	1.365 (3)	C22—C25	1.503 (2)
C8—H8	0.9500	C23—C24	1.386 (2)
C9—C10	1.418 (2)	C23—H23	0.9500
C9—H9	0.9500	C24—H24	0.9500
C11—C12	1.589 (2)	C25—H25A	0.9800
C11—H11A	0.9900	C25—H25B	0.9800
C11—H11B	0.9900	C25—H25C	0.9800
C12—C13	1.514 (2)

O1—S1—O2	119.04 (7)	C4—C12—S1	112.56 (10)
O1—S1—C19	108.44 (7)	C11—C12—S1	114.56 (10)
O2—S1—C19	108.59 (7)	C14—C13—C18	119.23 (14)
O1—S1—C12	108.09 (7)	C14—C13—C12	119.61 (14)
O2—S1—C12	106.19 (7)	C18—C13—C12	121.15 (14)
C19—S1—C12	105.71 (7)	C15—C14—C13	120.48 (15)
C2—N1—C10	119.52 (14)	C15—C14—H14	119.8
N1—C2—C3	119.83 (15)	C13—C14—H14	119.8
N1—C2—H2	120.1	C16—C15—C14	119.97 (16)
C3—C2—H2	120.1	C16—C15—H15	120.0
C4—C3—C2	120.88 (15)	C14—C15—H15	120.0
C4—C3—C11	94.75 (13)	C17—C16—C15	119.95 (15)
C2—C3—C11	144.35 (15)	C17—C16—H16	120.0
C3—C4—C5	122.04 (15)	C15—C16—H16	120.0
C3—C4—C12	93.72 (13)	C16—C17—C18	120.30 (15)
C5—C4—C12	144.13 (14)	C16—C17—H17	119.8
C4—C5—C6	127.03 (14)	C18—C17—H17	119.8
C4—C5—C10	113.29 (14)	C17—C18—C13	120.04 (15)
C6—C5—C10	119.62 (15)	C17—C18—H18	120.0
C7—C6—C5	120.10 (15)	C13—C18—H18	120.0
C7—C6—H6	120.0	C24—C19—C20	121.45 (14)
C5—C6—H6	120.0	C24—C19—S1	119.72 (12)
C6—C7—C8	120.50 (16)	C20—C19—S1	118.82 (12)
C6—C7—H7	119.8	C21—C20—C19	118.39 (15)
C8—C7—H7	119.8	C21—C20—H20	120.8
C9—C8—C7	120.81 (16)	C19—C20—H20	120.8
C9—C8—H8	119.6	C20—C21—C22	121.36 (15)
C7—C8—H8	119.6	C20—C21—H21	119.3
C8—C9—C10	120.68 (16)	C22—C21—H21	119.3
C8—C9—H9	119.7	C23—C22—C21	118.75 (14)
C10—C9—H9	119.7	C23—C22—C25	120.80 (15)
N1—C10—C9	117.39 (15)	C21—C22—C25	120.45 (15)
N1—C10—C5	124.33 (15)	C24—C23—C22	121.10 (15)
C9—C10—C5	118.27 (16)	C24—C23—H23	119.4
C3—C11—C12	85.29 (11)	C22—C23—H23	119.4
C3—C11—H11A	114.4	C23—C24—C19	118.94 (14)
C12—C11—H11A	114.4	C23—C24—H24	120.5
C3—C11—H11B	114.4	C19—C24—H24	120.5
C12—C11—H11B	114.4	C22—C25—H25A	109.5
H11A—C11—H11B	111.6	C22—C25—H25B	109.5
C13—C12—C4	119.07 (13)	H25A—C25—H25B	109.5
C13—C12—C11	115.51 (12)	C22—C25—H25C	109.5
C4—C12—C11	86.19 (11)	H25A—C25—H25C	109.5
C13—C12—S1	107.93 (10)	H25B—C25—H25C	109.5

C10—N1—C2—C3	−1.4 (2)	C19—S1—C12—C13	−173.08 (10)
N1—C2—C3—C4	−1.5 (2)	O1—S1—C12—C4	169.44 (10)
N1—C2—C3—C11	176.2 (2)	O2—S1—C12—C4	−61.76 (12)
C2—C3—C4—C5	3.6 (2)	C19—S1—C12—C4	53.49 (12)
C11—C3—C4—C5	−175.11 (14)	O1—S1—C12—C11	73.08 (12)
C2—C3—C4—C12	−179.50 (15)	O2—S1—C12—C11	−158.12 (11)
C11—C3—C4—C12	1.81 (12)	C19—S1—C12—C11	−42.87 (12)
C3—C4—C5—C6	174.77 (15)	C4—C12—C13—C14	−153.41 (14)
C12—C4—C5—C6	0.0 (3)	C11—C12—C13—C14	−52.97 (19)
C3—C4—C5—C10	−2.5 (2)	S1—C12—C13—C14	76.70 (16)
C12—C4—C5—C10	−177.23 (19)	C4—C12—C13—C18	25.7 (2)
C4—C5—C6—C7	−176.19 (15)	C11—C12—C13—C18	126.14 (15)
C10—C5—C6—C7	0.9 (2)	S1—C12—C13—C18	−104.18 (15)
C5—C6—C7—C8	−1.7 (2)	C18—C13—C14—C15	0.8 (2)
C6—C7—C8—C9	0.9 (3)	C12—C13—C14—C15	179.89 (15)
C7—C8—C9—C10	0.6 (3)	C13—C14—C15—C16	−1.6 (3)
C2—N1—C10—C9	−176.19 (15)	C14—C15—C16—C17	1.0 (3)
C2—N1—C10—C5	2.4 (2)	C15—C16—C17—C18	0.3 (3)
C8—C9—C10—N1	177.31 (15)	C16—C17—C18—C13	−1.2 (2)
C8—C9—C10—C5	−1.4 (2)	C14—C13—C18—C17	0.6 (2)
C4—C5—C10—N1	−0.5 (2)	C12—C13—C18—C17	−178.52 (14)
C6—C5—C10—N1	−177.98 (14)	O1—S1—C19—C24	160.91 (12)
C4—C5—C10—C9	178.11 (14)	O2—S1—C19—C24	30.22 (15)
C6—C5—C10—C9	0.6 (2)	C12—S1—C19—C24	−83.38 (14)
C4—C3—C11—C12	−1.74 (12)	O1—S1—C19—C20	−18.36 (15)
C2—C3—C11—C12	−179.8 (2)	O2—S1—C19—C20	−149.06 (12)
C3—C4—C12—C13	115.45 (14)	C12—S1—C19—C20	97.34 (13)
C5—C4—C12—C13	−69.0 (3)	C24—C19—C20—C21	−0.1 (2)
C3—C4—C12—C11	−1.73 (12)	S1—C19—C20—C21	179.12 (12)
C5—C4—C12—C11	173.8 (2)	C19—C20—C21—C22	0.2 (2)
C3—C4—C12—S1	−116.78 (11)	C20—C21—C22—C23	0.0 (2)
C5—C4—C12—S1	58.8 (3)	C20—C21—C22—C25	179.90 (15)
C3—C11—C12—C13	−118.96 (13)	C21—C22—C23—C24	−0.2 (2)
C3—C11—C12—C4	1.56 (11)	C25—C22—C23—C24	179.92 (15)
C3—C11—C12—S1	114.66 (11)	C22—C23—C24—C19	0.2 (2)
O1—S1—C12—C13	−57.12 (12)	C20—C19—C24—C23	0.0 (2)
O2—S1—C12—C13	71.67 (11)	S1—C19—C24—C23	−179.29 (12)

Hydrogen-bond geometry (Å, º) top

D—H···A	D—H	H···A	D···A	D—H···A
C23—H23···O2ⁱ	0.95	2.52	3.431 (2)	161
C24—H24···O1ⁱ	0.95	2.47	3.2357 (19)	137

Symmetry code: (i) −x+3/2, y−1/2, −z+1/2.

References

Dassonneville, B., Detert, H. & Schollmeyer, D. (2025). IUCrData 10, x250943. Google Scholar
Dassonneville, B., Hinkel, F. & Detert, H. (2023). Int. J. Org. Chem. 13, 16–39. CrossRef CAS Google Scholar
Letessier, J., Geffe, M., Schollmeyer, D. & Detert, H. (2013). Synthesis 45, 3173–3178. CAS Google Scholar
Limbach, D., Geffe, M. & Detert, H. (2018). ChemistrySelect pp 249–252. Google Scholar
Sheldrick, G. M. (2015a). Acta Cryst. A71, 3–8. Web of Science CrossRef IUCr Journals Google Scholar
Sheldrick, G. M. (2015b). Acta Cryst. C71, 3–8. Web of Science CrossRef IUCr Journals Google Scholar
Spek, A. L. (2009). Acta Cryst. D65, 148–155. Web of Science CrossRef CAS IUCr Journals Google Scholar
Stoe & Cie (2020). X-RED32 and X-AREA. Stoe & Cie, Darmstadt, Germany. Google Scholar

This is an open-access article distributed under the terms of the Creative Commons Attribution (CC-BY) Licence, which permits unrestricted use, distribution, and reproduction in any medium, provided the original authors and source are cited.
